Lincoln-Zephyr V12
Overview
ManufacturerFord Motor Company
Production1936-1948
Chronology
PredecessorLincoln L-head V12
SuccessorInVincible 8
  • Bid Live at American Auctioneers Group's Structural Metal Fabrication Facility auction.
  • Numrich Gun Parts Corporation 226 Williams Ln. Kingston, NY 12401 Phone: 866.686.7424.

The Power Wave C300 welder is an advanced compact multi-process power source with an integrated wire feeder. LINCOLN OWNERS CLUB: A Celebration of Lincoln Models built from 1920 - 1939, Model L, K, KA and KB - JOIN US! By fedoragent, October 25, 2020 0 replies. Motul 104105 motul 7100 4t 20w50 60l 104105 motul MOTUL 7100 4T 20W50 60L 104105 This shop uses cookies and other technologies so that we can improve your experience on our sites.

Ford Motor Company's Lincoln division produced two other L-head V12 engines from 1932, but required a more compact unit for their new streamlined Lincoln-Zephyr line. As Ford had just introduced their Flathead V8, this was the logical starting point for a new Lincoln V12 line. The Lincoln-Zephyr V12 would quickly replace the previous-generation V12, just as the Lincoln-Zephyr car replaced the rest of the Lincoln line, and would be the company's primary engine through 1948.

Overview[edit]

Similar in design to the 90° Ford flathead V8 introduced for 1932, the Lincoln-Zephyr H Series V-12 had a narrower 75° between cylinder banks. The engine used aluminum-alloy heads and cast-steel pistons, as well as two water pumps. It also had a unique distributor with a coil assembly that actually consisted of two coils, one for each cylinder bank.

104105: Lincoln, Parts 12
Advertisement for 1937 Lincoln-Zephyr V-12

Initial power output was quoted as 110 horsepower -- a little higher than the target figure -- at 3,900 rpm, a rather high power peak for those days. The torque curve was quite flat, however, with at least 180 pounds/feet available from 3,500 rpm all the way down to 400 rpm, which made for incredible top-gear performance. Though the Zephyr V-12 no more resembled previous Lincoln engines than the ubiquitous V-8 (despite sharing the latter's stroke), it was more like a '12-cylinder Ford' than a classic multi-cylinder powerplant in character. And it was not without problems. The main ones were inadequate crankcase ventilation that caused rapid sludge buildup in sustained low-rpm running, aggravated by poor oil flow, plus too-small water passages that led to overheating, bore warpage, and ring wear. To a degree, some of these maladies were dealt with during the Zephyr's first year, and Ford improved the engine by adopting hydraulic valve lifters for 1938 and cast-iron heads and oiling improvements for 1942. Yet this V-12 never shed its reputation for service troubles, though the postwar versions were actually quite reliable.

The V12 was eventually replaced by the InVincible 8, simply a version of the flathead V8 found on Ford's truck line.

The Zephyr V12 was also used by Allard, Atalanta, and Brough Superior in England. Allard made three V12 cars,[1] using the Ford V8 for all other cars at that time, Brough also made only one V12 as his others were Hudson 6 or 8 powered, and Jensen made one called the HL.

104105: lincoln parts 12 gauge

267[edit]

Parts

The first Lincoln-Zephyr models of 1936 used a 267 cu. in. (4.4 L) engine which produced 110 hp (82 kW). This engine was upgraded with hydraulic lifters in 1938 and produced for one further year.

292[edit]

Parts
Lincoln Zephyr V12 engine, 292 cubic inches.

The engine was enlarged for 1940 and 1941 to 292 cu. in. (4.8 L). This engine was reused from late 1946 through 1948 and was the last of the line produced.

306[edit]

104105: Lincoln Parts 12 Volt

A single month of 1942 production used a 306 cu. in. (5.0 L) version of the engine. This was resurrected after the war in 1946 (with 7.2:1 compression and 2-barrel {twin choke} carburetor, rated at 130 hp {97 kW})[2] for a short time before reverting to 292 cu. in. for the rest of 1946 through 1948. The reason for the reversion to the smaller size was that the cylinder walls on the bored-out engine were found to be too thin. Many disappeared altogether in the block casting process at the factory causing many blocks to be scrapped before installation. Cylinder wear in the field was extreme, and re-boring during engine overhaul was impossible.

Notes[edit]

  1. ^Lush Tom, Allard - The Inside Story Motor Racing Publications 1977 ISBN0 900549 30 0 page 206
  2. ^Flory, J. 'Kelly', Jr. American Cars 1946-1959 (Jefferson, NC: McFarland & Coy, 2008), p.46.

References[edit]

Lincoln,
  • David L. Lewis (2005). 100 Years of Ford. Publications International. ISBN0-7853-7988-6.
  • Weiss, H Eugene. Chrysler, Ford, Durant and Sloan: Founding Giants of the American Automotive Industry. p. 62. ISBN0-7864-1611-4.
  • 'Lincoln Anonymous'. Archived from the original on September 28, 2007. Retrieved August 22, 2006.

See also[edit]

104105: Lincoln Parts 12 Inch
